Industrial Tray Drying Oven
Offer end in:
A robust industrial tray drying oven with forced air circulation, digital PID temperature control, and heavy insulation, suitable for industrial, laboratory, and R&D drying applications.
Read More...
Capacity
Out Of Stock
Clear
Description
The LEW-124 Industrial Tray Drying Oven is a heavy-duty drying solution designed for industrial production, laboratory processing, and R&D applications requiring reliable and uniform heat distribution. The oven is equipped with strong axial flow fans that provide heavy forced air circulation with cross-flow, ensuring consistent temperature uniformity across all tray levels.
Heating is achieved through special-grade tubular air heaters strategically placed in the circulating air path for maximum efficiency. The unit features a microprocessor-based Digital PID temperature control system, offering superior temperature accuracy along with over-temperature and over-current protection for safe operation. An adjustable air damper allows controlled exhaust of moist air, fumes, or vapors, improving drying efficiency and process control.
Constructed as a sturdy triple-walled structure, the oven uses heavy-gauge mild steel sheets and reinforced mild steel sections. The cavity between walls is packed with high-grade mineral wool insulation, minimizing heat loss and reducing energy consumption. The interior chamber is coated with high-temperature aluminum paint, while the exterior is powder-coated for durability and corrosion resistance.
Brackets are provided along the inner walls to support heavily loaded trays at adjustable heights. The unit is supplied without trays, allowing users to select aluminum or Stainless Steel (SS-304) trays as per application requirements (available at extra cost). With a temperature range of 50°C to 250°C, the LEW-124 Tray Drying Oven is ideal for drying, curing, and heating processes across multiple industries.
Heating is achieved through special-grade tubular air heaters strategically placed in the circulating air path for maximum efficiency. The unit features a microprocessor-based Digital PID temperature control system, offering superior temperature accuracy along with over-temperature and over-current protection for safe operation. An adjustable air damper allows controlled exhaust of moist air, fumes, or vapors, improving drying efficiency and process control.
Constructed as a sturdy triple-walled structure, the oven uses heavy-gauge mild steel sheets and reinforced mild steel sections. The cavity between walls is packed with high-grade mineral wool insulation, minimizing heat loss and reducing energy consumption. The interior chamber is coated with high-temperature aluminum paint, while the exterior is powder-coated for durability and corrosion resistance.
Brackets are provided along the inner walls to support heavily loaded trays at adjustable heights. The unit is supplied without trays, allowing users to select aluminum or Stainless Steel (SS-304) trays as per application requirements (available at extra cost). With a temperature range of 50°C to 250°C, the LEW-124 Tray Drying Oven is ideal for drying, curing, and heating processes across multiple industries.
Specifications of Industrial Tray Drying Oven
| Product Type | Industrial Tray Drying Oven |
| Temperature Range: | 50°C to 250°C |
| Air Circulation | Heavy forced air circulation with axial flow fans |
| Heating Method | Tubular air heaters in air circulation path |
| Controller | Microprocessor-based Digital PID Temperature Controller |
| Display Options | LED / LCD / TFT Touch Screen (Optional) |
| Power Monitoring | Voltage & ampere meters provided |
| Capacity | 12 Tray , 12 Tray , 24 Tray |
