FETAL MONITOR

Share on:

Offer end in:

Pulse Vital FM Fetal Monitor is designed for monitoring fetal heart rate and uterine activity during pregnancy. It features a 10-inch LED-backlit touchscreen with a 60° folding angle for convenient viewing. The monitor uses a high-sensitivity digital pulse transducer and DSP technology for signal processing, with optional twin-pregnancy monitoring. Its built-in thermal printer, data storage, and wireless connectivity support efficient clinical monitoring and documentation.

In Stock

Description Specification

Pulse Vital FM Fetal Monitor is designed to monitor fetal heart rate and uterine activity, supporting routine antenatal assessment in clinical settings. It features a 10-inch LED-backlit touchscreen with a 60° folding angle for clear visualization and convenient operation. The device uses a 1 MHz digital pulse transducer with 12-chip high sensitivity and digital signal processing (DSP) technology for fetal signal analysis. It measures fetal heart rate within a range of 30–240 bpm, with a resolution of 1 bpm and an accuracy of ±1 bpm. The monitor includes upper and lower fetal heart rate alarm limits for real-time alerts and supports optional twin-pregnancy monitoring. Its TOCO measurement range is 0–100%, with 1% resolution, and it provides manual fetal movement marking. The built-in high-resolution thermal printer offers six print modes with a 112 mm printing width, while internal storage supports up to 1,200 hours of data and waveform records. Bluetooth and wireless connectivity options enable data transfer and compatibility with central monitoring systems, and the device operates on AC 220 V ±20%, 50 Hz power.

Specifications of FETAL MONITOR

Shipping Weight	5 kg
Shipping Dimensions	114.30 × 114.30 × 114.30 cm
Display	10" LED backlight touchscreen with 60° folding angle
Digital Pulse Transducer	1 MHz digital pulse transducer with 12-chip high sensitivity
Twins Monitoring	Twins monitoring capability (optional)
Signal Processing	DSP technology for signal processing
FHR Alarms	Upper/lower limit alarms for real-time alerts
Automatic Diagnosis	Automatic diagnosis with reforming Fischer score
Print Modes	6 print modes with 112 mm printing width
