BIPHASIC DEFIBRILLATOR DELUX (BLUE)

Share on:

Offer end in:

Pulse Vital ZBDP Biphasic Defibrillator Delux (Blue) is a multifunctional cardiac care device designed for defibrillation, ECG monitoring, and emergency response. It features a 7-inch color TFT display with manual defibrillation and AED modes. The device offers selectable energy levels from 2 to 200 joules, along with audible and visual alarms and advanced ECG monitoring capabilities. Its integrated thermal printer records ECG waveforms and treatment events for convenient clinical documentation.

In Stock

Description Specification

Pulse Vital ZBDP Biphasic Defibrillator Delux (Blue) is designed to support emergency cardiac care through defibrillation, ECG monitoring, and patient parameter observation. It features a 7-inch color TFT display with a 150 × 90 mm display area and front-panel controls for convenient operation. The device supports manual defibrillation using a biphasic truncated exponential waveform, with selectable energy levels from 2 to 200 joules in 12 steps. It includes external paddles for adult and pediatric use, with synchronized cardioversion and shock delivery through paddles or compatible pads. The ECG monitoring system supports Lead I, II, and III, adjustable gain settings, digital signal processing, and sweep speeds of 12.5, 25, and 50 mm/sec. The monitor displays ECG and other supported parameters, including SpO₂, NIBP, and EtCO₂, with 24-hour graphical and tabular trend storage. AED mode provides rhythm analysis, voice and text prompts, and a 200-joule shock level when indicated. An integrated thermal printer records ECG waveforms, event details, energy settings, and shock status for clinical documentation. With mains charging, a compact design measuring up to 280 × 330 × 220 mm, and an approximate weight of 6.5 kg, the device is suitable for emergency and hospital environments.

Specifications of BIPHASIC DEFIBRILLATOR DELUX (BLUE)

Shipping Weight	6.5 kg
Shipping Dimensions	28.00 × 33.00 × 22.00 cm
Display	7" Colour TFT
Display Area	150 mm × 90 mm
Unit ON–OFF	By front panel keyboard, Encoder
Operation	User adjustable high & low limit, audible and visual alarming
Alarm	24 hrs graphical and tabular trend of ECG, SpO₂, NIBP, EtCO₂
Charge/Discharge Control	Charge and Shock button on front panel and paddles
Paddle Assembly	External paddle assembly with coil retractable high voltage cable, Adults & Pediatric paddle integrated to same handle
